Key Features Of The TTT Titan Temperature Transmitter
Multi-Sensor Technology Support
- Compatible with PT100, PT1000, NTC, PTC resistance thermometers and thermocouples for maximum measurement flexibility.
Dual Output Configurations
- Available in analogue (TTTa) and digital (TTTd) versions to suit diverse system requirements and integration needs.
Advanced Signal Processing
- Precision-calibrated and thermally compensated electronics deliver highly stable and accurate temperature readings.
Versatile Output Protocols
- Supports 0.5 to 4.5V ratiometric or regulated analogue outputs, digital I2C and SPI interfaces, and standard resistance or thermocouple signals.
Superior Environmental Protection
- Ingress protection up to IP66 with integrated cable outlet or M12 x 1, 4-pin connector for reliable operation in harsh environments.
Customizable Configuration Options
- Available with adjustable probe lengths, multiple process connections, and tailored specifications for OEM applications.
Industrial Temperature Measurement Solutions Using The TTT Titan Sensor
The TTT Titan Temperature Transmitter is engineered for versatility and reliability across a wide spectrum of industrial and OEM applications. Its multi-sensor compatibility, advanced signal processing, and flexible output options make it the ideal choice for precise thermal measurement in demanding environments.
Suitable applications include:
- HVAC and climate control systems
- Industrial process monitoring and control
- Refrigeration and cryogenic applications
- Pharmaceutical and laboratory equipment
- Food and beverage processing
- Chemical and petrochemical industries
- Energy production and thermal management
- Automotive and transportation systems
- Medical device manufacturing / testing
- Environmental monitoring and data logging
- Building automation and facility management
- Water treatment and management systems
- Academic research
TTT Titan Temperature Transmitter Technical Specifications
| Parameter | Specification |
|---|---|
| Sensor Types Supported | PT100, PT1000, NTC, PTC, Thermocouples |
| Output Options | Analogue (TTTa) or Digital (TTTd) |
| Analogue Output Range | 0.5 to 4.5V (ratiometric or regulated) |
| Digital Interfaces | I2C, SPI |
| Ingress Protection Rating | IP66 |
| Connector Options | Integrated cable outlet or M12 x 1, 4-pin |
| Enclosure Material | Stainless Steel |
| Probe Configuration | Customizable lengths and process connections |
| Signal Stability | Highly stable with thermal compensation |
| Calibration | Precision-calibrated for each application |
| Thermal Compensation | Active thermal compensation included |
| Operating Environment | Demanding industrial conditions |
| Connector Type | M12 x 1, 4-pin (standard) or cable outlet |
