SRT-94 Temperature Meter with a Large, 20 mm High LED Display

The SRT-94 is tailored for precise temperature measurement, supporting Pt100/500/1000 and various thermocouples (K, S, J, T, N, R, B, E). It provides linearised readings for dependable accuracy. The meter powers transducers with a 24V DC output and offers RS-485 for data transmission. It features REL / OC outputs for signal control and allows customisation with various analog outputs. Easy to configure via keyboard or S-Config software, the SRT-94 is your solution for versatile and precise temperature monitoring.

SRT 94 Temperature Meter Product Parameters

  • Output Signal: 0, 2, or 4x REL or OC outputs; analogue output options available.
  • Accuracy: 0.1% @25°C ± one digit.
  • Electrical Connections: Power supply 19V ÷ 50V DC, 16V ÷ 35V AC, 85 ÷ 260V AC/DC.
  • Process Connections: Inputs for thermoresistance Pt100, Pt500, Pt1000, and various thermocouples.
  • Media Compatibility: Operating temp. 0°C to +50°C, storage temp. -10°C to +70°C.
  • Special Features: LED display, adjustable brightness, RS-485 interface, IP 65/20 protection, panel mounting.

Product Highlights

The SRT94 Temperature Meter is a versatile device designed for accurate temperature measurements. It features a resistance-type Pt100/500/1000 input or thermocouple input compatible with K, S, J, T, N, R, B, and E type thermocouples. The inputs have fully linearised characteristics for reliable readings. The meter offers a 24V DC / 100 mA output for powering measuring transducers and an RS-485 port for data transmission in production process monitoring systems. It includes REL/OC control outputs to adjust the measured signal level based on one or two threshold values. Analogue outputs can be added, such as active current output, passive isolated current output, or active voltage output. Configuration is possible through the local keyboard or S-Config software via the RS-485 port. With its precision and user-friendly features, the SRT94 Temperature Meter is an excellent choice for temperature measurement applications in various industries.

Features

  • Temperature meter with a large, 20 mm high, LED display
  • Input: thermoresistance or thermocouple
  • 0, 2 or 4 REL / OC outputs
  • Analogue output: active or passive, power supply output: 24V DC
  • RS-485 / Modbus RTU
  • Automatic recognition of 3 and 4-conductor connection (RTD inputs)
  • Automatic compensation of TC cold ends temperature
  • Free configuration software S-Config

To download the latest datasheet click here: SRT 94
